A Mechanistic Analysis of Sim-and-Real Co-Training in Generative Robot Policies

Overview

What is Co-Training?

Co-training — combining limited in-domain real-world data with abundant surrogate data such as simulation^1,2,3, cross-embodiment robot data^4,5, or even cross-modality data⁶ — is widely used for training generative visuomotor policies. One strategy is to simply do mixed training. However, despite its empirical success, the mechanisms that determine when and why co-training is effective remain poorly understood.

What We Do

We investigate the working principles of sim-and-real co-training through theoretical analysis and multi-layered empirical study, and identify structured representation alignment as the primary intrinsic effect governing performance improvement. We validate these effects with controlled toy model experiments and extensive sim-and-sim and sim-and-real robotic manipulation experiments. Our analysis provides a unified interpretation of recent co-training techniques and motivates a simple method that achieves consistent improvements over prior approaches.

A Bit of Theoretical Insights: Two Intrinsic Effects

Training a co-trained diffusion policy corresponds to jointly learning a feature encoder $f_\phi:\mathcal{O}\rightarrow\mathcal{Z}$ and a policy model $\pi_\theta:\mathcal{Z}\rightarrow\mathcal{A}$. Through our analysis, we identify that there exists one intrinsic effect in each space.

Structured Representation Alignment: in the latent space $p(\mathcal{Z})$

We prove the existence of an analytical optimal solution, which reveals that the behavior of the co-trained score function depends on the learned representations. Based on their alignment structure, three scenarios emerge:

Importance Reweighting: in the conditional action space $p(\mathcal{A|Z})$

Another effect further modulates the action sampling distribution by reweighting score functions across domains. Define $r_k(a^t,t) := \frac{||a^t - \alpha_t a_k||}{\sigma_t \sqrt{d}}$, the relative weight between target and source samples follows:

$g_{k}=\text{Softmax}\big(\ln(w_k) - r_k^2 \cdot d/2\big), \quad w_t = w/N,\; w_s = (1-w)/M$

In special case we can have: $\frac{g_r}{g_s} = \frac{1-w_N}{w_N}\cdot \frac{w}{1-w} \cdot \exp(\frac{r_s^2 - r_r^2}{2})$

The amplitude of this modulation depends on three factors: (i) the mixing ratio $w$, (ii) the dataset sizes $N$ and $M$, and (iii) the domain gaps between source and target actions.

Illustrative Toy Models

To disentangle and understand the individual contributions of both effects, we design controlled toy co-training experiments. The policy model learns a mapping $\pi(y|x):\mathbb{R}^3 \rightarrow \mathbb{R}^2$, where we manually define source and target manifolds with different distributions and alignment structures. The adjustment of the data mixing ratio $w$ controls the importance reweighting effect:

Observations on Real Robots

Alignment Can Be Learned Implicitly

We visualize the latent embeddings with UMAP across different mixing ratios. Within a certain range of balanced mixing ratios ($w \in [0.016, 0.3]$), the shallow layers exhibit local geometry alignment while the deep layer features show global alignment — all without any explicit alignment objective. The phenomenon holds consistently across different tasks.

Alignment Correlates with Performance

The correlation between representation alignment (measured by Wasserstein distance) and task success rate is moderate-to-strong, with Pearson and Spearman coefficients in the range of $0.6 \sim 0.8$ across all settings except pure physics-only gaps.

Discernibility is Indispensable

Existence of Three Representation Regimes

We introduce an additional and complementary control knob via discriminator regularization, which directly modulates domain discernibility. Specifically, we train models with discriminator loss weights of $\{0, 0.05, 0.5\}$, and within each setting sweep the mixing ratio to vary alignment.

We can observe distinct behavior patterns in three regimes: (1) negative correlation in overlapping regime; (2) weak positive correlation in structured aligned regime; (3) strong positive correlation in disjoint regime.

A Unified View of Co-Training Methods

Existing co-training techniques can be understood through the lens of how they improve representation alignment and domain discernibility. We revisit three representative approaches, and further propose a simple combination method.

Sim-and-Sim Experiments

Real-World Evaluation

We evaluate all methods in sim-and-real co-training on three challenging manipulation tasks, with 15 trials each:

Takeaways

1. Primary intrinsic effect in co-training: structured representation alignment: Structured representation alignment influences the latent condition space, while importance reweighting modulates the conditional action space.
2. Both alignment and discernibility are necessary: representation alignment correlates with performance, while blind alignment without domain awareness leads to negative transfer, especially with the existence of physics domain gaps.
3. Representation alignment can be learned implicitly and progressively: with balanced mixing ratios without any explicit alignment objective: from local geometry alignment in shallow layers to global alignment in deep layers.
4. A principled guideline for mixing ratio selection. We also provide a coarse range of balanced mixing ratios, which we believe can be a useful starting point for future large-scale co-training experiments, narrowing down the search space.

References

• [1] Wei, Adam, et al. Empirical Analysis of Sim-and-Real Cotraining of Diffusion Policies for Planar Pushing from Pixels. IROS, 2025.
• [2] Maddukuri, Abhiram, et al. Sim-and-Real Co-Training: A Simple Recipe for Vision-Based Robotic Manipulation. RSS, 2025.
• [3] Cheng, Shuo, et al. Generalizable domain adaptation for sim-and-real policy co-training. NeurIPS, 2025.
• [4] Punamiya, Ryan, et al. Egobridge: Domain adaptation for generalizable imitation from egocentric human data. NeurIPS, 2025.
• [5] Kareer, Simar, et al. Emergence of Human to Robot Transfer in Vision-Language-Action Models. Preprint, 2025.
• [6] Lin, Fanqi, et al. A Systematic Study of Data Modalities and Strategies for Co-training Large Behavior Models for Robot Manipulation. Preprint, 2026.
